5-18 Service Manual
7558-xxx
Go Back
Previous
Next
Developer drive motor
Plug/Jack Callout Plug/jack description Connects to
P/J74 2
P/J75 1
P/J251 4 PC/developer drive motor Lower engine PCBA
P/J252 3
PC/developer drive motor
Lower engine PCBA
