MacDon FD75 - Page 218

214323 200 Revision A
1022778
A
Figure 3.338: John Deere S7 Display –
Harvesting Page
4. On the HARVESTING page, select the MENU icon (A)
in the bottom right corner of screen. The MENU opens.
1022786
A
B
Figure 3.339: John Deere S7 Display – Machine
Settings
5. Select the MACHINE SETTINGS tab (A),
6. Select the CALIBRATIONS & PROCEDURES icon (B).
The CALIBRATIONS & PROCEDURES page displays.
1022797
A
B
Figure 3.340: John Deere S7 Display –
Calibrations and Procedures
7. Select HEADER tab (A).
8. Select HEADER CALIBRATION (B). The HEADER
CALIBRATION page displays.
OPERATION
