214323 285 Revision A
Figure 4.36: Challenger and Massey Ferguson
Figure 4.37: Gleaner R and S Series
10. Use the lock handle (B) to retract the lugs (A) at the
base of the feeder house.
Figure 4.38: Adapter on Combine
11. Lower the feeder house until the saddle (A) disengages
and clears the adapter support.
12. Back the combine away slowly from the adapter.
HEADER ATTACHMENT/DETACHMENT
