214323 298 Revision A
Figure 4.67: Driveline
5. Slide the driveline into hook (A) until disc (B) drops
securing the driveline in place.
Figure 4.68: Coupler
6. Remove electrical connector from adapter
receptacle (A).
7. Unscrew knob (B) on coupler (C) to release the coupler
from adapter receptacle (D).
Figure 4.69: Cover
8. Remove cover (A) from the combine receptacle.
HEADER ATTACHMENT/DETACHMENT
