214323 308 Revision A
Figure 4.91: Adapter Receptacles
11. Replace cover (A) on the adapter receptacle.
Figure 4.92: Feeder House Locks
12. Lift lever (A) and pull and lower handle (B) to disengage
feeder house/adapter lock (C).
Figure 4.93: Header on Combine
13. Lower feeder house (A) until it (A) disengages from
adapter support (B).
14. Back the combine slowly away from the header.
HEADER ATTACHMENT/DETACHMENT
