MacDon FD75 - Page 41

214323 23 Revision A
Table 2.2 Header Attachments
CA25 Combine Adapter S
Feed draper Width
2000 mm (78.7 in.) S
Feed draper
Speed
107–122 m/min
(350–400 fpm)
S
Feed auger Width
1660 mm (65.3 in.) S
Feed auger
Outside diameter 559 mm (22 in.) S
Feed auger Tube diameter
356 mm (14 in.) S
Feed auger
Speed (varies with
combine model)
150 rpm
S
Oil reservoir capacity
(60 litres)
16 US gallons
S
Oil type
15W40
—
Driveline
overall length
5
Case, New Holland
Maximum (extended) 1230 mm (48.4 in.)
O
F
Minimum (compressed) 970 mm (38.2 in.)
Challenger, Gleaner,
John Deere, CLAAS,
Massey Ferguson
Maximum (extended) 1262 mm (49.7 in.)
Minimum (compressed) 916 mm (36.1 in.)
Upper Cross Auger O
D
Flighting (outside diameter [O.D]) 305 mm (12 in.)
—
Tube diameter (O.D)
All sizes except 7.6 m
(25 ft.)
152 mm (6 in.)
—
7.6 m (25 ft.) 178 mm (7 in.)
Stabilizer Wheel / Slow Speed Transport O
D
Wheels
381 mm (15 in.)
—
Tires
P205/75 R-15
—
Weight
Estimated weight range includes base header and 2000 lb. combine adapter (variances are due to
different package configurations)
9.1 m (30-ft.) header
3060–3162 kg (6746–6971 lb.)
10.6 m (35-ft.) header
3251–3370 kg (7167–7430 lb.)
12.2 m (40-ft.) header
North America frame
3442–3533 kg (7589–7789 lb.)
12.2 m (40-ft.) header Export frame
3549 kg (7824 lb.)
13.7 m (45-ft.) header
North America frame
3728 kg (8218 lb.)
13.7 m (45-ft.) header Export frame
3744 kg (8253 lb.)
PRODUCT OVERVIEW
5. Subtract 265 mm (10-7/16 in.) for length between yoke pins.
