Figure 3.65: Torque Wrench
12. Place wrench (A) back onto right leg of adapter.
Figure 3.66: Wing Lock in Lock Position
13. Lock the wings by moving spring handles (A) to upper
LOCK position.
Figure 3.67: Linkage Cover
14. Reinstall linkage cover (A) and secure it with bolt (B).
