MacDon M1240 - Page 176

215916 156 Revision A
1015634
A
Figure 4.85: Electrical Connectors
12. Remove the cover from receptacle (A), and connect the
electrical harness from the header.
1015478
A
B
Figure 4.86: Left Cab-Forward Platform
13. Push latch (A) to unlock platform (B).
1012700
A
Figure 4.87: Left Cab-Forward Platform
14. Pull platform (A) towards the cab until it stops and the latch
is engaged.
OPERATION
