215916 309 Revision A
4.8 Operating with an R85 Rotary Disc Header
4.8.1 Setting Disc Speed
This adjustment requires the header to be in operation.
DANGER
Ensure that all bystanders have cleared the area.
1019651
A
Figure 4.449: Disc Header Run Screen 1
1. If RUN SCREEN 1 is not already displayed, press soft
key 1 (A) on the Harvest Performance Tracker (HPT) to
display RUN SCREEN 1.
1020174
A
B
Figure 4.450: GSL
2. Press disc speed switch (A) on GSL to increase disc speed,
or switch (B) to decrease speed.
3. Refer to screen (as shown in Step 1, page 309) for speed
display.
4.8.2 Adjusting Disc Pressure Alarm
Adjusting the disc alarm allows the operator to set an alert to inform them that the disc is operating at a desired pressure.
A lower setting will cause the alarm to be set off more often; a higher setting will allow the alarm to be set off less
frequently. This adjustment requires the header to be in operation.
DANGER
Ensure that all bystanders have cleared the area.
