215916 436 Revision A
Figure 5.166: Steering Rods beneath the Cab
Figure 5.167: Steering Rods – Pump End
2. Check steering rod bolts (A) for looseness.
3. Ensure ball joints (B) feel firm, but can be moved by hand.
NOTE:
Ball joints that are excessively loose or too stiff to pivot by
hand should be replaced.
Figure 5.168: Steering Link
4. Check steering link bolts (A) for looseness.
5. Ensure ball joints (B) feel firm but can be moved by hand.
NOTE:
Ball joints that are excessively loose or too stiff to pivot by
hand should be replaced.
MAINTENANCE AND SERVICING
