215916 462 Revision A
1. Shut down the engine, and remove the key from
the ignition.
1014848
A
Figure 5.216: Fuse Box Location
2. Open battery cover (A) to access the fuse box. For
instructions, refer to Opening Battery Cover, page 427.
1020162
A
B
Figure 5.217: Fuse Box Cover
3. Lift latch (A) at top of fuse box cover (B) to disengage the
tab, and then lower the cover.
4. Check and replace the fuses as required. For instructions,
refer to Checking and Replacing Fuses, page 463.
5. Position cover (B) onto the fuse panel, ensuring that the
hooks at the bottom of the cover have engaged the
fuse panel.
6. Push latch (A) to engage the tab at top of the fuse box.
7. Close the battery cover and move the platform to working
position. For instructions, refer to 5.4.2 Closing Platform,
page 337.
MAINTENANCE AND SERVICING
