Checking and Replacing Fuses
Figure 5.218: Fuses
1. To check a fuse, pull fuse (A) out of the receptacle and
visually examine it.
2. To replace a fuse, insert a new fuse into the receptacle.
IMPORTANT:
Replacement fuses should match the rating on the decal
shown on Fuse Panel and Relay Module Decals, page 465.
Replacing Circuit Breakers and Relays
DANGER
To prevent bodily injury or death from the unexpected startup of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
1. Shut down the engine, and remove the key from the ignition.
2. Open the fuse box cover. For instructions, refer to 5.15.7 Accessing Circuit Breakers and Fuses, page 461.
