6.3 Transport
Several kits are available which facilitate moving the header from field to field.
6.3.1 Ballast
Ballast kits are for draper headers only. For operation on steep hills, additional ballast sets (beyond the recommendation in
the table) may be installed.
Initial rear ballast package (MD #B6053): 1 unit (163 kg [360 lb.])
Additional rear ballast package (MD #B6054): 2 units (163 kg [360 lb.] each)
Installation instructions are included.
Table 6.3 Ballast
Header Type
Description
Installed Options
Base Kit
Additional
Kits
Additional
Float Springs
D125X
25 foot, single reel,
double knife, timed
–
00 0
D130XL
30 foot, single reel,
double knife, timed
Transport
1
00
D130XL
30 foot, single reel,
double knife, timed
Transport + upper cross
auger + vertical knives
1
0 MD #B6047
D135XL
35 foot, single reel,
double knife, untimed
Base
11
0
D135XL
35 foot, single reel,
double knife, untimed
Transport
11
MD #B6047
D135XL
35 foot, single reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2
MD #B6047
D135XL
35 foot, double reel,
double knife, untimed
Base
11 0
D135XL
35 foot, double reel,
double knife, untimed
Transport
1 1 MD #B6047
D135XL
35 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2
MD #B6047
D140XL
40 foot, double reel,
double knife, untimed
Base
11 0
D140XL
40 foot, double reel,
double knife, untimed
Transport
1 1 MD #B6047
D140XL
40 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
12
MD #B6047
D145XL
45 foot, double reel,
double knife, untimed
Base
11
MD #B6047
D145XL
45 foot, double reel,
double knife, untimed
Transport
12
MD #B6047
D145XL
45 foot, double reel,
double knife, untimed
Transport + upper cross
auger + vertical knives
1
2
MD #B6106
