215916 32 Revision A
Lights High Performance
Lighting
12 lights: 4 halogen road, 8 LED work lights
System Monitoring
Display
178 mm (7 in.) LCD
Speeds
Ground (mph or km/h), engine (rpm), knife (spm), reel
(rpm or mph / km/h), conveyor (rpm or mph / km/h), cooling
fan (rpm)
Pressures
Knife (psi or MPa), reel (psi or MPa), conveyor (psi or MPa),
supercharge (psi or MPa)
Header position
Platform
Height, angle, float
Reel
Height, fore-aft
Engine parameters
Fuel consumption, load
Tire Options
Drive
Bar
600/65R28
Turf
580/70R26
Caster
Suspended
16.5L-16.1 with independent suspension
Frame and Structure
Dimensions
Refer to 2.3 Windrower Dimensions, page 33
Frame to ground (crop clearance)
1160 mm (45.7 in.)
Walking beam maximum width
3856 mm (151.8 in.) with 3422 mm (134.7 in.) crop clearance
Weight
2
Base
3
6078 kg (13,400 lb.)
Max GVW
10,660 kg (23,500 lb.)
Max CGVW
11,794 kg (26,000 lb.)
Header compatibility Draper D1XL Series, D1X Series Draper Header
Rotary Disc
R85 4.9 m (16 ft.), R113, R216 Rotary Disc Header
Auger
A40DX Series
PRODUCT OVERVIEW
2. Weights do not include options.
3. Weight with 600-65R28 bar tires, no fuel/DEF. Hydraulic oil and coolant included in weight.
