215916 512 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
23 521497 1
Electrical
System
Engine ECM Offline
Engine Control Module
Offline
First check if cooling module door is open or cooling
module door sensor is defective. If not then check
engine control module connectors & module fuse; if
ok, Contact Dealer.
23 521498
1
Electrical
System
CAN 1 Offline CAN 1 Offline Check CAN Harnessing; if ok, Contact Dealer
23 521499
1
Electrical
System
CAN 2 Offline CAN 2 Offline Windrower lighting and HVAC will not be operational.
Check CAN Harnessing; if ok, Contact Dealer.
23 521500 1
Electrical
System
CAN 3 Offline CAN 3 Offline Check CAN Harnessing; if ok, Contact Dealer
23 521515
1
Windrower Water In Fuel Water In Fuel Detected
Water in the fuel can do extensive damage to the fuel
system, due to the tight tolerances of the fuel system
components.The fuel filter must be drained
immediately.
25 168
1
Electrical
System
HVAC
Low voltage - Below normal,
most severe
Check HVAC power supply. Contact dealer.
25 170 3
Electrical
System
HVAC
Cab temp open circuit -
Voltage above normal
Inspect cab temperature and wiring. Contact Dealer
25 170
4
Electrical
System
HVAC
Cab temp shorted - Voltage
below normal
Inspect cab temperature and wiring. Contact Dealer
25 442 3
Electrical
System
HVAC
Duct temp open circuit -
Voltage above normal
Check HVAC duct temperature sensor wiring. Contact
Dealer.
25 442
4
Electrical
System
HVAC
Duct temp shorted - Voltage
below normal
Check HVAC duct temperature sensor wiring. Contact
Dealer.
25 520193
5
Electrical
System
HVAC
Clutch low amps - Current
below normal
Inspect A/C clutch wiring for damage. Contact Dealer.
25 520193 6
Electrical
System
HVAC
Clutch high amps - Current
above normal
Inspect A/C clutch wiring for damage. Contact Dealer.
25 520194 3
Electrical
System
HVAC
Evaporator temp open
circuit - Voltage above
normal
Check temperature sensor and wiring at the
evaporator. Contact dealer.
25 520194
4
Electrical
System
HVAC
Evaporator temp shorted -
Voltage below normal
Check temperature sensor and wiring at the
evaporator. Contact dealer.
34 521517
1
Header
System
LH Knife Sensor ETDK Sensor Fault LH knife speed sensor fault. Sensor output not
responding as expected relative to knife pressure
REFERENCE
