MacDon M1240 - Page 533

215916 513 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
34 521518 1
Header System
LH Knife Speed ETDK Knife Over Speed LH knife speed has exceeded 200SPM
34 521519
1
Header System
LH Knife Valve ETDK Bypass Valve LH bypass valve at 100%. Verify valve is functional
34 521521
1
Header System
RH Knife Sensor ETDK Sensor Fault RH knife speed sensor fault. Sensor output not
responding as expected relative to knife pressure
34 521522
1
Header System
RH Knife Speed
ETDK Over Speed
RH knife speed has exceeded 200SPM
34 521523
1
Header System
RH Knife Valve ETDK Bypass Valve RH bypass valve at 100%. Verify valve is functional
34 521525
1
Header System
Knife Control
ETDK Open Loop
ETDK Knife speed control is in open loop control
34 521528
1
Header System
STW Controller Offline STW Controller Offline The controller is offline. Check CAN harness.
34 521536
1
Header System
Knife Control ETDK Max Knife pressure
Knife pressure at maximum (3000 PSI)
34 521537 2
Header System
Knife Control ETDK Min Knife pressure
Knife pressure below minimum (200 PSI), with knife speed sensor reporting a speed.
104 521000 3
Electrical System
Fuel Level Sender Low Alarm Sensor voltage below 0.4V. Check sensor power
supply. Replace sensor if necessary.
104 521000
4
Electrical System
Fuel Level Sender High Alarm
Sensor voltage above 4.7 V. Check for wiring damage. Replace sensor if necessary.
104 521000
5
Electrical System
Fuel Level Sender
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Check for wiring damage. Replace sensor if necessary.
104 521000 6
Electrical System
Fuel Level Sender High Error
Sensor voltage above 4.95 V. Check for wiring damage. Replace sensor if necessary.
104 521000 8
Electrical System
Fuel Level Sender
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521003 3
Electrical System
GSL Position
Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Replace sensor if necessary.
104 521003
4
Electrical System
GSL Position
High Alarm
Sensor voltage above 4.65 V. Check for wiring damage. Replace sensor if necessary.
