MacDon M1240 - Page 535

215916 515 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521024 8
Electrical System
Reel Fore-Aft Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521027 3
Electrical System
Lateral Tilt Low Alarm Sensor voltage below 0.5V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521027
4
Electrical System
Lateral Tilt High Alarm
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521027
5
Electrical System
Lateral Tilt
Low Error
Sensor voltage below 0.5V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521027 6
Electrical System
Lateral Tilt High Error
Sensor voltage above 4.5 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521027 8
Electrical System
Lateral Tilt
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521030 3
Electrical System
LH Float Cyl. Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521030
4
Electrical System
LH Float Cyl. High Alarm
Sensor voltage above 4.7 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521030
5
Electrical System
LH Float Cyl.
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521030 6
Electrical System
LH Float Cyl. High Error
Sensor voltage above 4.9 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521030 8
Electrical System
LH Float Cyl.
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521033 3
Electrical System
Converyor Pressure
Low Alarm Sensor voltage below 0.45V. Check sensor power
supply and replace sensor as necessary. Ensure that DWA option (in Attachments menu) is checked off only if it is in fact installed.
104 521033
4
Electrical System
Conveyor Pressure
High Alarm
Sensor voltage above 4.7 V. Check for wiring damage and replace sensor as necessary. Ensure that DWA option (in Attachments menu) is checked off only if it is in fact installed.
REFERENCE
