MacDon M1240 - Page 536

215916 516 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521033
5
Electrical System
Conveyor Pressure
Low Error
Sensor voltage below 0.025V. Check sensor power supply and replace sensor as necessary. Ensure that DWA option (in Attachments menu) is checked off only if it is in fact installed.
104 521033 6
Electrical System
Conveyor Pressure
High Error Sensor voltage above 4.9 V. Check for wiring damage
and replace sensor as necessary. Ensure that DWA option (in Attachments menu) is checked off only if it is in fact installed.
104 521033 8
Electrical System
Conveyor Pressure
Vref Error Reference voltage error. Check sensor wiring for
damage. Ensure that DWA option (in Attachments menu) is checked off only if it is in fact installed.
104 521036 3
Electrical System
RH Float Cyl. Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521036
4
Electrical System
RH Float Cyl. High Alarm Sensor voltage above 4.7 V. Check for wiring damage.
Adjust and re-calibrate or replace sensor if necessary.
104 521036
5
Electrical System
RH Float Cyl.
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521036 6
Electrical System
RH Float Cyl. High Error Sensor voltage above 4.9 V. Check for wiring damage.
Adjust and re-calibrate or replace sensor if necessary.
104 521036 8
Electrical System
RH Float Cyl. Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521039 3
Electrical System
Knife Pressure
Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Replace sensor if necessary.
104 521039
4
Electrical System
Knife Pressure High Alarm Sensor voltage above 4.7 V. Check for wiring damage.
Replace sensor if necessary.
104 521039
5
Electrical System
Knife Pressure
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Replace sensor if necessary.
104 521039 6
Electrical System
Knife Pressure High Error Sensor voltage above 4.9 V. Check for wiring damage.
Replace sensor if necessary.
104 521039 8
Electrical System
Knife Pressure Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521042 3
Electrical System
Reel Pressure Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Replace sensor if necessary.
REFERENCE
