Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
104 521042
4
Electrical System
Reel Pressure High Alarm
Sensor voltage above 4.7 V. Check for wiring damage. Replace sensor if necessary.
104 521042
5
Electrical System
Reel Pressure
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Replace sensor if necessary.
104 521042 6
Electrical System
Reel Pressure High Error
Sensor voltage above 4.9 V. Check for wiring damage. Replace sensor if necessary.
104 521042 8
Electrical System
Reel Pressure
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521045 3
Electrical System
Header Tilt Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521045
4
Electrical System
Header Tilt High Alarm
Sensor voltage above 4.7 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521045
5
Electrical System
Header Tilt
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521045 6
Electrical System
Header Tilt High Error
Sensor voltage above 4.9 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521045 8
Electrical System
Header Tilt
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521048 3
Electrical System
Header Height Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Adjust and re-calibrate or replace sensor if necessary.
104 521048
4
Electrical System
Header Height High Alarm
Sensor voltage above 4.7 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521048
5
Electrical System
Header Height
Low Error
Sensor voltage below 0.025V. Check sensor power supply. Adjust and re-calibrate or replace sensor if necessary.
104 521048 6
Electrical System
Header Height High Error
Sensor voltage above 4.9 V. Check for wiring damage. Adjust and re-calibrate or replace sensor if necessary.
104 521048 8
Electrical System
Header Height
Vref Error Reference voltage error. Check sensor wiring for
damage.
104 521051 3
Electrical System
Charge Pressure Low Alarm Sensor voltage below 0.45V. Check sensor power
supply. Replace sensor if necessary.
REFERENCE
