MacDon M1240 - Page 550

215916 530 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
176 521111
5
Electrical System
Low Beam Light Cab Fwd EK2 Relay coil is not
receiving power
Check wiring to roof relay module EK2. Contact dealer.
176 521111 6
Electrical System
Low Beam Light Cab Fwd EK2 Relay Normally open
contact is shorted
Check roof relay module
176 521111
7
Electrical System
Low Beam Light Cab Fwd EK2 Relay Normally closed
contact is shorted
Check roof relay module
176 521119 1
Electrical System
Tail Lights Engine Fwd EK3 Relay coil open or not
present
Check roof relay module
176 521119 2
Electrical System
Tail Lights Engine Fwd EK3 Relay Coil shorted or
failed relay driver
Check roof relay module
176 521119 3
Electrical System
Tail Lights Engine Fwd EK3 Relay Normally Open
contact is open
Check roof relay module
176 521119
4
Electrical System
Tail Lights Engine Fwd EK3 Relay Normally Closed
contact is open
Check roof relay module
176 521119
5
Electrical System
Tail Lights Engine Fwd EK3 Relay coil is not
receiving power
Check wiring to roof relay module EK3. Contact dealer.
176 521119 6
Electrical System
Tail Lights Engine Fwd EK3 Relay Normally open
contact is shorted
Check roof relay module
176 521119
7
Electrical System
Tail Lights Engine Fwd EK3 Relay Normally closed
contact is shorted
Check roof relay module
176 521127
1
Electrical System
Outer Work Lights EK4 Relay coil open or not
present
Check roof relay module
176 521127 2
Electrical System
Outer Work Lights EK4 Relay Coil shorted or
failed relay driver
Check roof relay module
176 521127 3
Electrical System
Outer Work Lights EK4 Relay Normally Open
contact is open
Check roof relay module
176 521127
4
Electrical System
Outer Work Lights EK4 Relay Normally Closed
contact is open
Check roof relay module
176
521127
5
Electrical System
Outer Work Lights EK4 Relay coil is not
receiving power
Check wiring to roof relay module EK4. Contact dealer.
176 521127 6
Electrical System
Outer Work Lights EK4 Relay Normally open
contact is shorted
Check roof relay module
176 521127
7
Electrical System
Outer Work Lights EK4 Relay Normally closed
contact is shorted
Check roof relay module
REFERENCE
