MacDon M1240 - Page 551

215916 531 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
176 521135 1
Electrical System
Rear Roof Work Lights
EK5 Relay coil open or not present
Check roof relay module
176 521135 2
Electrical System
Rear Roof Work Lights
EK5 Relay Coil shorted or failed relay driver
Check roof relay module
176 521135 3
Electrical System
Rear Roof Work Lights EK5 Relay Normally Open
contact is open
Check roof relay module
176 521135
4
Electrical System
Rear Roof Work Lights
EK5 Relay Normally Closed contact is open
Check roof relay module
176 521135
5
Electrical System
Rear Roof Work Lights EK5 Relay coil is not
receiving power
Check wiring to roof relay module EK5. Contact dealer.
176 521135 6
Electrical System
Rear Roof Work Lights EK5 Relay Normally open
contact is shorted
Check roof relay module
176 521135
7
Electrical System
Rear Roof Work Lights
EK5 Relay Normally closed contact is shorted
Check roof relay module
176 521143
1
Electrical System
High Beam Lights CF EK6 Relay coil open or not
present
Check roof relay module
176 521143 2
Electrical System
High Beam Lights CF EK6 Relay Coil shorted or
failed relay driver
Check roof relay module
176 521143 3
Electrical System
High Beam Lights CF EK6 Relay Normally Open
contact is open
Check roof relay module
176 521143
4
Electrical System
High Beam Lights CF EK6 Relay Normally Closed
contact is open
Check roof relay module
176
521143
5
Electrical System
High Beam Lights CF EK6 Relay coil is not
receiving power
Check wiring to roof relay module EK6. Contact dealer.
176 521143 6
Electrical System
High Beam Lights CF EK6 Relay Normally open
contact is shorted
Check roof relay module
176 521143
7
Electrical
System
High Beam Lights CF EK6 Relay Normally closed
contact is shorted
Check roof relay module
176
521151
1
Electrical System
Brake Lights, Eng Fwd EK7 Relay coil open or not
present
Check roof relay module
176 521151 2
Electrical System
Brake Lights, Eng Fwd EK7 Relay Coil shorted or
failed relay driver
Check roof relay module
176 521151 3
Electrical System
Brake Lights, Eng Fwd EK7 Relay Normally Open
contact is open
Check roof relay module
REFERENCE
