MacDon M1240 - Page 553

215916 533 Revision A
Fault Codes
Telltale
Short
Description
Full Fault
Description
Recommended
Fix/Check Message
SA SPN FMI
176 521167
7
Electrical System
Beacon Lights EK9 Relay Normally closed
contact is shorted
Check roof relay module
176 521175
1
Electrical System
Dome Light, Cab EK10 Relay coil open or not
present
Check roof relay module
176 521175 2
Electrical System
Dome Light, Cab EK10 Relay Coil shorted or
failed relay driver
Check roof relay module
176 521175 3
Electrical System
Dome Light, Cab EK10 Relay Normally Open
contact is open
Check roof relay module
176 521175
4
Electrical System
Dome Light, Cab EK10 Relay Normally Closed
contact is open
Check roof relay module
176 521175
5
Electrical System
Dome Light, Cab EK10 Relay coil is not
receiving power
Check wiring to roof relay module EK10. Contact dealer.
176 521175 6
Electrical System
Dome Light, Cab EK10 Relay Normally open
contact is shorted
Check roof relay module
176 521175
7
Electrical System
Dome Light, Cab EK10 Relay Normally closed
contact is shorted
Check roof relay module
176 521185
1
Electrical System
Inner Work Lights EC1 Circuit Breaker Blown
Check roof relay module
176 521185 2
Electrical System
Inner Work Lights EC1 Circuit Breaker Not
Powered
Check wiring to roof relay module EC1 circuit breaker. Contact dealer.
176 521288
1
Electrical System
Outer Work Lights EC2 Circuit Breaker Blown Check roof relay module
176
521288 2
Electrical System
Outer Work Lights EC2 Circuit Breaker Not
Powered
Check wiring to roof relay module EC2 circuit breaker. Contact dealer.
176 521291
1
Electrical System
Brake Lights, Eng Fwd EC3 Circuit Breaker Blown
Check roof relay module
176 521291 2
Electrical System
Brake Lights, Eng Fwd EC3 Circuit Breaker Not
Powered
Check wiring to roof relay module EC3 circuit breaker.
Contact dealer.
176 521294 1
Electrical System
Low Beam Light Cab Fwd EC4 Circuit Breaker Blown
Check roof relay module
176 521294 2
Electrical System
Low Beam Light Cab Fwd EC4 Circuit Breaker Not
Powered
Check wiring to roof relay module EC4 circuit breaker. Contact dealer.
176 521297
1
Electrical System
Rear Swath Lights EC5 Circuit Breaker Blown Check roof relay module
