215916 548 Revision A
J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN
Description
Detail
105 15
Check
Engine
None
2964
Engine Intake Manifold #1
Intake Manifold 1 Temperature -
Data valid but above normal
operating range - Least Severe
Level
105 16
Check
Engine
Amber
488
Engine Intake Manifold
Intake Manifold 1 Temperature -
Data valid but above normal
operating range - Moderately
Severe Level
107
15
Eng Air
Filter
Amber
5576
Engine Air Filter 1
Differential Pressure
Engine Air Filter Differential
Pressure - Data valid but above
normal operating range - Least
Severe Level
107 16
Eng Air
Filter
Amber
3341
Engine Air Filter 1
Differential Pressure
Engine Air Filter Differential
Pressure - Data valid but above
normal operating range -
Moderately Severe Level
108 3
Check
Engine
Amber
221 Barometric Pressure
Barometric Pressure Sensor
Circuit - Voltage above normal, or
shorted to high source
108 4
Check
Engine
Amber
222 Barometric Pressure
Barometric Pressure Sensor
Circuit - Voltage above normal, or
shorted to low source
110 0
Eng
coolant
temp
Red
151
Engine Coolant
Temperature
Engine Coolant Temperature -
Data valid but above normal
operational range - Most
Severe Level
110 3
Check
Engine
Amber
144
Engine Coolant
Temperature
Engine Coolant Temperature 1
Sensor Circuit - Voltage above
normal, or shorted to high source
110 4
Check
Engine
Amber
145
Engine Coolant
Temperature
Engine Coolant Temperature 1
Sensor Circuit - Voltage below
normal, or shorted to low source
110 16
Eng
coolant
temp
Amber
146
Engine Coolant
Temperature
Engine Coolant Temperature -
Data valid but above normal
operating range - Moderately
Severe Level
110 31
Check
Engine
None 2659
Engine Coolant
Temperature
Engine Coolant Temperature -
Condition Exists
111 1
Coolant
Level
Red
235
Engine Coolant Level
Coolant Level - Data valid but
below normal operational range -
Most Severe Level
111
3
Check
Engine
None 6522
Engine Coolant Level
Coolant Level Sensor 1 Circuit -
Voltage above normal, or shorted
to high source
111
4
Check
Engine
None 6523
Engine Coolant Level
Coolant Level Sensor 1 Circuit -
Voltage below normal, or shorted
to low source
111 9
Check
Engine
Amber
3613
SAE J1939 Multiplexing
PGN Timeout
SAE J1939 Multiplexing PGN
Timeout Error - Abnormal
update rate
