J1939
SPN
J1939
FMI
Telltale
Lamp
Cummins
Fault Code
J1939_SPN
Description
Detail
111
17
Coolant
Level
Amber
(Blinking)
2448
Engine Coolant Level
Coolant Level - Data valid but
below normal operating range -
Least Severe Level
111 18
Coolant
Level
Amber
197
Engine Coolant Level
Coolant Level - Data valid but
below normal operating range -
Moderately Severe Level
111
19
Check
Engine
Amber
3614
SAE J1939 Multiplexing
PGN Timeout
Coolant Level Sensor - Received
Network Data in Error
157
0
Stop
Engine
Red
449
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but above normal
operational range - Most
Severe Level
157 3
Check
Engine
Amber
451
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure
Sensor Circuit - Voltage above
normal, or shorted to high source
157 4
Check
Engine
Amber
452
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure
Sensor Circuit - Voltage below
normal, or shorted to low source
157 16
Check
Engine
Amber
553
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but above normal
operating range - Moderately
Severe Level
157 18
Check
Engine
Amber
559
Engine Injector Metering
Rail 1
Injector Metering Rail 1 Pressure -
Data valid but below normal
operating range - Moderately
Severe Level
168 15
Battery
None 6256
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
above normal operating range -
Moderately Severe Level
168 16
Battery
Amber
442
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
above normal operating range -
Moderately Severe Level
168
17
Battery
None 6257
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
below normal operating range -
Moderately Severe Level
168 18
Check
Engine
Amber
249
Battery Potential / Power
Input 1
Battery 1 Voltage - Data valid but
below normal operating range -
Moderately Severe Level
171
3
Check
Engine
Amber
256
Ambient Air Temperature
Ambient Air Temperature Sensor
1 Circuit - Voltage above normal,
or shorted to high source
171 4
Check
Engine
Amber
3531
Ambient Air Temperature
Ambient Air Temperature Sensor
1 Circuit - Voltage below normal,
or shorted to low source
171 9
Check
Engine
Amber
234
Ambient Air Temperature
Ambient Air Temperature -
Abnormal update rate
175
3
Check
Engine
None
689
Engine Oil Temperature 1
Engine Oil Temperature Sensor 1
Circuit - Voltage above normal, or
shorted to high source
