NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 105
Revision 3.0
ASYD
Note: When assigning data for INDEXes 56 and 57, be sure to assign data in such a way that the data value of
INDEX 56 is larger than INDEX 57 (Value of INDEX 56>Value of INDEX 57).
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
56 FF
b
0
Set Line Load Control (Automatic) Execution Occupancy
Rate.
Set execution of line load control (automatic) by the usage rate
(occupancy) rate of the CPU. (Ex.)
For executing line load control by CPU usage rate (occupancy
rate) 90%, assign 5AH.
To assign this Index, take the occupancy rate desired and con-
vert this value to Hex (e.g., 90 = 5Ah).
b
1
b
2
b
3
b
4
b
5
b
6
b
7
57 FF
b
0
Set Line Load Control (Automatic) Execution Cancel Occu-
pancy Rate.
Set cancellation of line load control (automatic) by the usage
rate (occupancy) rate of the CPU.
(Ex.)
For cancelling line load control by CPU usage rate (occupancy
rate) 80%, assign 50H.
To assign this Index, take the occupancy rate desired and con-
vert this value to Hex (e.g., 80 = 50H).
b
1
b
2
b
3
b
4
b
5
b
6
b
7
