NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 122
Revision 3.0
ASYD
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
191
0
b
0
Not used
0
b
1
b
2
Grades of System Message that can be Registered:
0 0 = Register All System Message Data
0 1 = Register System Message Data higher than grade
1 (SUP, MN, MJ)
1 0 = Register System Message Data higher than grade
2 (MN, MJ)
1 1 = Register System Message Data higher than grade
3 (MJ)
Note: This data is fixed to “00” when Alarm Grade data is
assigned by the ALMG command.
b
3
b
4
External Supplied Clock to
TDSW (12.352M-24CH Sys-
tem No. 0)
When one PLO card is to be
mounted:
When two PLO cards are to
be mounted:
b
5
External Supplied Clock to
TDSW (12.352M-24CH Sys-
tem No. 1)
b
6
External Supplied Clock to
TDSW (12.288M-32CH Sys-
tem No. 0*)
b
7
External Supplied Clock to
TDSW (12.288M-32CH Sys-
tem No. 1*)
b
3
b
2
b
7
b
6
b
5
b
4
0101
b
7
b
6
b
5
b
4
1111
