ND-70348 (E) CHAPTER 4
Page 153
Revision 5.0
ASYD
Note 1:
Maximum eight ports (port 0 through 7)
Note 2:
Port No. 7 is not available for use.
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
171
b
0
This data designates how many times retry is allowed when
Room Data image transfer fails (usually, 10 Hex).
(for Hotel
system)
b
1
b
2
b
3
b
4
b
5
b
6
0
b
7
Fixed “0”
172
b
0
Message Waiting
Data transfer to/from
PMS when executing
the service.
0/1 = Not Executed/
Executed
b
1
Message Registration
b
2
Do Not Disturb, Room Cutoff
b
3
Room Status
b
4
Automatic Wake-Up, Group An-
nouncement
b
5
Room Change, Room Swap
b
6
Room Data Change
0
b
7
Not used
173
b
0
Designation of Printer output ports for Hotel features.
Note 1
b
0
= Port 0 b
3
= Port 3 b
6
= Port 6
b
1
= Port 1 b
4
= Port 4 b
7
= Port 7
Note 2
b
2
= Port 2 b
5
= Port 5
(for Hotel
system)
b
1
b
2
b
3
b
4
b
5
b
6
b
7
174
0
b
0
-b
4
Not used
b
5
SMDR output method in CCIS/ISDN tandem node.
Specify the information of calling party in the outgoing call via No.7 CCIS
(calling party's number in ISDN).
0 = Station Number
Note
1 = Route Number of incoming trunk
Note:
In No.7 CCIS network, the number is limited to 6 digits including
the node number of RT=0 in the ARNP command.
0
b
6
-b
7
Not used
