NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 198
Revision 4.0
ASYD
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 31
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
3
2
b
0
Station Release Timer (TS) is
to be assigned a value from 1
Hex to F Hex (1~15). (Release
timing when connected to an
ORT)
ORT = 128 + (64
×
2
×
TS)
Note: When this data is 00
Hex, default data is
automatically set to
256 ms. (TS)
b
1
b
2
b
3
b
4
Answer after Station Release
and Hooking Timer (TL) is to
be assigned a value from 1
Hex to F Hex (1~15). (SHF
maximum timing)
SHF = 64 + (64
×
2
×
TL)
Note: When this data is 00
Hex, default data is
automatically set to
1082 ms. (TL)
b
5
b
6
b
7
3
b
0
2 Burst (0.4 sec.–ON, 0.2 sec.-OFF, 0.4 sec.–ON) on the ON
Time for Ringer Pattern 0
0/1 = Not Required/Required
b
1
2 Burst (0.4 sec.–ON, 0.2 sec.–OFF, 0.4 sec.–ON) on the ON
Time for Ringer Pattern 1
0/1 = Not Required/Required
0
b
2
Not used
0
b
3
0
b
4
b
5
3 Burst (0.4 sec.–ON, 0.2 sec.–OFF, 0.8 sec.–ON, 0.2 sec.–OFF,
0.4 sec.-ON) on the ON Time for Ringer Pattern 5
0/1 = Not Required/Required
0
b
6
Not used
0
b
7
Allow Bit 0 to be reset to 0
0/1 = No/Yes
4 00 Not used
5 00 Not used
