ND-70348 (E) CHAPTER 4
Page 203
Revision 4.0
ASYDL
SYS-
TEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
512-1535
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
515
IP Address (Hex) for PBX over External LAN
Note :
This data is valid when the PBX is connected to the external PC
LAN.
When default IP address (172.16.253.0) for the PBX is used, this data
setting is not necessary.
Example :
IP Address : 133.206.8.1
Note :
After changing this data, System Initialization (Non-Load Ini-
tialization) is required.
516
517
518
519
Subnet Mask (Hex) for PBX over External LAN
Note :
This data is valid when the PBX is connected to the external PC
LAN.
When default IP address (172.16.253.0) for the PBX is used, this data
setting is not necessary.
Example :
Subnet Mask : 255.255.0.0
Note :
After changing this data, System Initialization (Non-Load Ini-
tialization) is required.
520
521
522
523
Default Gateway Address of External LAN
Gateway Address (IP address of Router) of Network connecting PBX.
Note :
This data is valid when the PBX is connected to the external PC
LAN.
In the case of no Network Gateway, assignment data is 00 Hex.
in Index 523 through 526.
Example :
Default Gateway Address : 133.206.8.254
Note :
After changing this data, System Initialization (Non-Load Ini-
tialization) is required.
524
525
526
INDEX Set Hex
515 85
516 CE
517 08
518 01
INDEX Set Hex
519 FF
520 FF
521 00
522 00
INDEX Set Hex
523 85
524 CE
525 08
526 FE
