NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 215
Revision 4.0
ASYDL
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
512-1535
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
865
FPC (Fusion Point Code) of the node providing IP
(Assign 0 when the ACD service is activated in the self node
only.)
FPC: 1-253 (01 Hex – FD Hex)
Note:
This data is necessary at all nodes.
Assign the self FPC at the node providing ACDP.
866
FPC (Fusion Point Code) of the node providing ACDP
(Assign 0 when the OAI service is activated in the self node
only.)
FPC: 1-253 (01 Hex – FD Hex)
Note 1:
This data is necessary at all nodes.
Assign the self FPC at the node providing ACDP.
Note 2:
When OAI and ACD functions are used together
in a Netfusing network, enter the same FPC value
in INDEXes 865 and 866.
867~895 Not used
896 b
0
~b
7
FPC (Fusion Point Code) of the node providing PMS
897
b
0
PMS Interface
0/1 = RS-232C/LAN
0b
1
~b
3
Not used
b
4
ACK/NAK control while text sending/receiving in PMS LAN
connection
0 = ACK/NAK control is invalid
1 = ACK/NAK control is valid
Note: Available for the software Release 10 or later.
0b
5
~b
7
Not used
898~927 Not used
928
(For 16-IMG system)
Fixed to “0”.
929
b
0
~b
3
TSW card accommodation on ISWM in 16-IMG system
0/1 = Not accommodated/Accommodated
b0: TSW0 b2: TSW2
b1: TSW1 b3: TSW3
b
4
~b
7
Not used
Note: Assign the same FPC to INDEX 865 and INDEX 866.
