ND-70348 (E) CHAPTER 4
Page 362
Revision 4.0
ADSL
3. Data Entry Instructions
DISP
DISPSOFT KEY PATTERN
(SKP) 0-15
STATUS NUMBER
(SN) 0-15
FUNCTION KEY DATA
(FKY) 1-320
26
12
2
1
The soft key indication is
displayed when DISP has assigned
by the AFDD command.
SN
0 = Idle
1 = Originating (DT connection)
2 = Originating (RBT connection)
3 = Called station busy (BT connection)
4 = Communication in progress (Converse)
5 = Consultation Hold (Controlling Station)
6 = Trunk busy (BT connection)
7 = Not used
8 = Consultation Hold when Called Station is
Busy - Controlling Station
9 = 3-Party Conference Call
10-14 = Not used 15 = Others
SKN
Soft key number (SKN)
appears on the MAT.
SKP
Assign arbitrary
number within 0
through 15.
0 = Soft key pattern
shared in a system
1-15 = Soft key pattern
alloted to each
station
SKN
0-15
Note 1
Note 2
Note 2
Note 1
See Table 4-17-1 (Next Page).
Note 1: Available only for the Station to which Busy Service is applied.
Note 2: Available for software Release 9 or later.
To Next Page
