NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 402
Revision 3.0
ARTD
RT
FUNCTION
REMARKS
73
KPST Duration of KP sending
0= 48 msec. 1= 56 msec.
2= 64 msec. 3= 72 msec.
4= 80 msec. 5= 88 msec.
6= 96 msec. 7= 104 msec.
8= 112 msec. 9= 120 msec.
10= 128 msec. 11= 136 msec.
12= 144 msec. 13= 152 msec.
14= 160 msec. 15= 168 msec.
(In case of MFC)
0= 12.0 sec. 1= 5.5 sec.
2= 7.0 sec. 3= 8.5 sec.
4= 10.0 sec. 5= 11.5 sec.
6= 13.0 sec. 7= 14.5 sec.
8= 16.0 sec. 9= 17.5 sec.
10= 20.0 sec. 11= 22.0 sec.
12= 24.0 sec. 13= 26.0 sec.
14= 28.0 sec. 15= 30.0 sec.
When the monitor sig-
nal is Reverse and the
data is set to “0”, KP
sending is stopped by
reserve signal monitor
at the related distant
office.
Note: Use this when
ONSG/INSG =
4.(MF)
74
KPPT Pause after KP sending
0= 48 msec. 1= 56 msec.
5= 88 msec. 6= 96 msec.
7= 104 msec. 8= 112 msec.
12= 144 msec. 13= 152 msec.
14= 160 msec. 15= 168 msec.
(In case of MFC)
0= 12.0 sec. 1= 5.5 sec.
2= 7.0 sec. 3= 8.5 sec.
4= 10.0 sec. 5= 11.5 sec.
6= 13.0 sec. 7= 14.5 sec.
8= 16.0 sec. 9= 17.5 sec.
10= 20.0 sec. 11= 22.0 sec.
12= 24.0 sec. 13= 26.0 sec.
14= 28.0 sec. 15= 30.0 sec.
Note: Use this when
ONSG/INSG
= 4.(MF)
75
STC Stop Code
0-11= Not used 12= MF
13= Not used 14= DTMF
15= MF (for MF signaling)
Use this when ONSG/
INSG = 4.(MF)
76
MC MP Start Cause
0= As per ST 1= Not used
This data must always
be set to “0”.
77
MT MF Frequency
0= DTMF (4×4) 1= MF (2 out of 6)
Use this when ONSG/
INSG = 4.(MF)
78
TONE TONE Designation for TRK Call Termination
0= DT 1-15= Not used
This data is effective
when 2 (Second Dial
Tone) is set in ARTD,
ISGS = 3.
Note
Note
