ND-70348 (E) CHAPTER 4
Page 403
Revision 3.0
ARTD
RT
FUNCTION
REMARKS
79
PPTM Sender Prepares
0= Standard Note 1 1= 600 msec.
2= 800 msec. 3= 1000 msec.
4= 1200 msec. 5= 1400 msec.
6= 1600 msec. 7= 1800 msec.
8= 2000 msec. 9= 2200 msec.
10= 2400 msec. 11= 2600 msec.
12= 2800 msec. 13= 3000 msec.
14= 3200 msec. 15= 3400 msec.
(In case of MFC)
0= 24.0 sec. 1= 5.5 sec.
2= 7.0 sec. 3= 8.5 sec.
4= 10.0 sec. 5= 11.5 sec.
6= 13.0 sec. 7= 14.5 sec.
8= 16.0 sec. 9= 17.5 sec.
10= 20.0 sec. 11= 22.0 sec.
12= 24.0 sec. 13= 26.0 sec.
14= 28.0 sec. 15= 30.0 sec.
Note 1: Depends on
the data in
SYS1, Index
131 of ASYD.
80
MPTM Sender Minimum Pause
0= 10 PPS/600 msec., 20 PPS/450 msec.
1= 600 msec. 2= 800 msec.
3= 1000 msec. 4= 1200 msec.
5= 1400 msec. 6= 1600 msec.
7= 1800 msec. 8= 2000 msec.
9= 2200 msec. 10= 2400 msec.
11= 2600 msec. 12= 2800 msec.
13= 3000 msec. 14= 3200 msec.
15= 3400 msec.
(In case of MFC)
0= 12.0 sec. 1= 5.5 sec.
2= 7.0 sec. 3= 8.5 sec.
4= 10.0 sec. 5= 11.5 sec.
6= 13.0 sec. 7= 14.5 sec.
8= 16.0 sec. 9= 17.5 sec.
10= 20.0 sec. 11= 22.0 sec.
12= 24.0 sec. 13= 26.0 sec.
14= 28.0 sec. 15= 30.0 sec.
Note:
Possible to
use when ad-
justing the
interdict tim-
er in DP line.
Note
To Next Page
