NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 412
Revision 3.0
ARTDN
4. Data Sheet
LGRT
1-899
FUNCTION
REMARKS
1
OSGS Signal Interface for Outgoing
0= CCIS No.7 1= RingDown
2= Second Dial Tone 3= Not used
4= Sender (Immediate Start) Note
5= Not used
6= Sender (Delay Dial Start)
7= Sender (Wink start) 8-15= Not used
Note:
The select
signal in
ONSG
should be
“DP”.
2
ONSG Signal Selection for Outgoing
0= Not used 1= DP, 10 pps, 33% Make
2= PB, 60msec. Interruption or CCIS No.7
3= DP/PB 4= MF
5= DP, 20 pps, 33% Make
6= Not used
7= DP, 20 pps, 50% Make
8= PB, 120 msec. Interruption
9= DP, 10 pps, 40% Make
10= MFC 11-15= Not used
3
ISGS Signal Interface for Incoming
0= CCIS No.7 1= Ring Down
2= Second Dial Tone 3= Not used
4= Sender (Immediate Start) Note
5= Not used
6= Sender (Delay Dial Start)
7= Sender (Wink Start) 8-15= Not used
Note: The select
signal in
INSG
should be
“DP”.
4
INSG Signal Selection for Incoming
0= Not used 1= DP, 10 pps, 33% Make
2= PB, 60msec. Interruption or CCIS No.7
3= DP/PB 4= MF
5= DP, 20 pps, 33% Make
6= Not used
7= DP, 20 pps, 50% Make
8= PB, 120 msec. Interruption
9= DP, 10 pps, 40% Make
10= MFC 11-15= Not used
5
TF Type of Trunk Function
0= Not used
1= Outgoing Trunk (OGT)
2= Incoming Trunk (ICT)
3= Bothway Trunk (BWT)
