ND-70348 (E) CHAPTER 4
Page 436
Revision 3.0
ALRNN
Table 4-24 SMDR2 (ALRNN)
CONTENTS/INPUT 0123456789101112131415
b0
0-Detailed billing is not required for incoming calls.
××××
1-Detailed billing is required for incoming calls.
××××
b1
0-Detailed billing is required for toll and local outgo-
ing calls.
×× ××
1-Detailed billing is required only for toll outgoing
calls.
×× ××
b2, 3
0-
1-Metering pulses are used.
××××
2-
3-
LOGICAL ROUTE (LGRT) 1-899
REMARKSFUSION POINT CODE (FPC) 1-253
ROUTE NUMBER (RT) 1-255
24 OC
0 = -
1 = Originating Category Information is used
For MFC signaling
(Brazil and Mexico)
25 R/L
Attendant-Identification of Incoming Trunk Display.
0 = TN, RT, TK display
1 = C.O. Line Number display
26 RVSD
Trunk Reversal Identification
This data is necessary when a specific Trunk route provides
battery reversal for answer supervision.
0 = Battery Reversal System
1 = Third Wire System
27 TL Tone Level 0000Always assign data “0.
28 ANS
Answer signal from Trunk side.
0 = No answer signal is given.
1 = Answer signal is given.
29 TELP
Time Elapse Indication Service
0 = Out of Service 1 = In Service
Time Elapse Indication
(TELP) is a warning tone
sent to the caller after a
predetermined period of
time has elapsed (usually
three minutes).
30 PAD
This data determines Pad control on the ODT/DTI circuit
card.
TLT (EMT) DTI
0 = Depending on setting.
7 = Pad Off(0db) Pad Off(0db)
Pad=1-6: Actual PAD
value depends on PAD
ROM on the ODT/DTI
circuit card. (See Circuit
Card Manual.)
