NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 437
Revision 3.0
ALRNN
31 OGRL
Release timing for outgoing trunk connection.
0 = 608 msec. 1 = 224 msec.
2 = 288 msec. 3 = 352 msec.
4 = 416 msec. 5 = 480 msec.
6 = 544 msec. 7 = 608 msec.
8 = 672 msec. 9 = 736 msec.
10 = 800 msec. 11 = 864 msec.
12 = 928 msec. 13 = 992 msec.
14 = 1056 msec. 15 = 1120 msec.
• Normally assign
data “0”.
• For ISDN, see Table
4-25 (page 445) .
(Examples of Route
Class Settings)
32 ICRL
Release timing for incoming trunk connections.
0 = 288 msec. Note 1 = 224 msec.
2 = 288 msec. 3 = 352 msec.
4 = 416 msec. 5 = 480 msec.
6 = 544 msec. 7 = 608 msec.
8 = 672 msec. 9 = 736 msec.
10 = 800 msec. 11 = 864 msec.
12 = 928 msec. 13 = 992 msec.
14 = 1056 msec. 15 = 1120 msec.
• Normally assign
data “0”.
• For ISDN, see Table
4-25 (page 445)
(Example of Route
Class Settings).
Note: 160 msec. in
case of Loop
Dialing Trunk.
33 HD
Trunk Hold Timing.
0 = 10 sec. 1 = 2 sec.
2 = 4 sec. 3 = 6 sec.
4 = 8 sec. 5 = 10 sec.
6 = 12 sec. 7 = 14 sec.
8 = 16 sec. 9 = 18 sec.
10 = 20 sec. 11 = 22 sec.
12 = 24 sec. 13 = 26 sec.
14 = 28 sec. 15 = 30 sec.
Normally assign data
“0”.
34 GUARD
Ground Timer
Outgoing inhibit timing after trunk release.
0 = 3072 msec. 1 = 512 msec.
2 = 1024 msec. 3 = 1536 msec.
4 = 2048 msec. 5 = 2560 msec.
6 = 3072 msec. 7 = 3584 msec.
8 = 4096 msec. 9 = 4608 msec.
10 = 5120 msec. 11 = 5632 msec.
12 = 6144 msec. 13 = 6656 msec.
14 = 7168 msec. 15 = 7680 msec.
• Normally assign
data “0.”
• For ISDN, see Table
4-25 (page 445)
(Example of Route
Class Settings).
LOGICAL ROUTE (LGRT) 1-899
REMARKSFUSION POINT CODE (FPC) 1-253
ROUTE NUMBER (RT) 1-255
