NEC NEAX 7400 IMX User Manual

ND-70348 (E) CHAPTER 4
Page 93
Revision 3.0
ASYD
SYSTEM
DATA
TYPE
(SYS)
SYSTEM
DATA
INDEX
(INDEX)
0 – 511
DATA
(DATA)
00 – FF
(Hex)
BIT
CORRESPONDING
DATA
SYSTEM DATA CONTENTS
DATA
0/1
BIT
1
13
b
0
Authorization Code Check Sum-2
b
4
= Check Sum of Digit 0
b
3
= Check Sum of Digit 1
b
2
= Check Sum of Digit 2
b
1
= Check Sum of Digit 3
b
0
= Check Sum of Digit 4
0/1 = No Check Sum/Check Sum
b
1
b
2
b
3
b
4
b
5
b
6
b
7
14
b
0
Authorization Code Check Code-1 (0~9 Hex.)
Check Code = MOD
10
(b
4
× D0 + b
3
× D1 + b
2
× D2 + b
1
× D3 + b
0
× D4 + D5)
(b
0
~b
7
are indicated by INDEX 12)
b
1
b
2
b
3
b
4
Authorization Code Check Code-2 (0~9 Hex.)
Check Code = MOD
10
(b
4
× D0 + b
3
× D1 + b
2
× D2 + b
1
× D3 + b
0
× D4 + D6)
(b
0
~b
4
are indicated by INDEX 13)
b
5
b
6
b
7
15
b
0
Number of Trunk Group (TG) Busy Lamps for Attendant Con-
sole
0 (Hex):Out of Service
Assign 01(Hex) ~ 0A (Hex) for 1 ~ 10 busy lamps.
Note: Assign the lamps in the ATGL command.
b
1
b
2
b
3
0
b
4
Not used
0
b
5
0
b
6
0
b
7
