Figure 81: Captive screws to secure the risers
Legend
1 Riser 3 with latch 3 Riser 1
2 Riser 2 4 Captive screws that secure riser
To remove riser 3, unlock the latch to release the riser from the Controller
motherboard.
Controller Replacement Procedures
115
