Caution: Close the Pilot fan door within 60 seconds to maintain adequate
airow to properly cool the serv
er.
Open Pilot Top Cover
1 Press down on the push buon on the Pilot top cover to release the top
cover and use the recessed areas to slide the top cover toward the back of
the Pilot about 0.5 inches (12.7 mm).
Caution: Before removing the top cover of the Pilot, power o the Pilot
using Guided Maintenance. Removing the Pilot top cover before powering
o the Pilot might cause damage to the operating system on the Pilot.
Tip: Slide out the Pilot top cover by pressing down on the grooves located
on both sides of the cover.
Figure 150: Pilot top cover removal
Legend
1 Push buon to release top cover
2 Grooves to slide out top cover
2 Lift the cov
er o the Pilot chassis and set it aside.
Remove a Battery
1 Remove the baery by placing your nger or a pointed tool like a
screwdriver under the baery on the side nearest to the back of the Pilot
and gently lifting the baery out of the retainer.
Pilot Replacement Procedures
181
To Next Page
