Figure 151: Battery removal
Legend
1 Pilot baery
2 Baery socket
2 Place the baery on an antistatic mat.
Insert a Battery
1 Unpack the component from its shipping carton.
Note: Place the component on an antistatic mat if it must be set aside for
any reason.
2 Press the replacement baery into the baery retainer with the positive
side (+) facing upwards.
Figure 152: Battery insertion
Legend
1 Pilot baery
2 Baery socket
If the Pilot is congured to synchronize with a netw
ork time server using
the Network Time Protocol (NTP), the Oracle ILOM clock is reset as soon
Pilot Replacement Procedures
182
