Figure 23: Inner CMA connector mounted
Legend
1 Slide rail
2 Inner CMA connector
3 Clip
3 Insert the outer CMA connector into the end of the right sliding rail.
Figure 24: Outer CMA connector attached
Oracle FS1–2 Global Procedures
56
