Oracle FS1-2 User Manual

Table 12: Component placement with three Replication Engines (continued)
Component type RU space for installation RU space if a DE2-24C
DE follows RU 12
Controller-2 RU 25, RU 26 RU 23, RU 24
Remaining Drive Enclosures RU 27 to RU 42
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
If the Oracle FS System includes four Replication Engines, then follow the
placement shown in the following table:
Table 13: Component placement with four Replication Engines
Component type RU space for installation RU space if a DE2-24C
DE follows RU 10
Drive Enclosures RU 1 to RU 12 RU1 to RU10
Replication Engine-4 RU 13, RU 14 RU 11, RU 12
Replication Engine-3 RU 15, RU 16 RU 13, RU 14
Replication Engine-2 RU 17, RU 18 RU 15, RU 16
Replication Engine-1 RU 19, RU 20 RU 17, RU 18
Pilot-0 RU 21 RU 19
Pilot-1 RU 22 RU 20
Controller-1 RU 23, RU 24 RU 21, RU 22
Controller-2 RU 25, RU 26 RU 23, RU 24
Remaining Drive Enclosures RU 27 to RU 42
RU 25 to RU 28 (next
DE2-24C DE)
RU 29 to RU 42
Component Numbering
Oracle FS Systems support tw
o Pilots (Pilot-1 and Pilot-2). Additionally,
Oracle FS Systems support two Controllers (Controller-1 and Controller-2) and 1
to 30 Drive Enclosures (DE-1 to DE-30).
The chassis ID number of the Drive Enclosure is based on the order by which the
Controller identies the Drive Enclosures. Drive Enclosures are also assigned a
chassis ID number in the Oracle FS System Manager GUI that is labeled
Enclosure Chassis ID. The chassis ID number can be changed using the GUI. The
chassis ID number displayed on the chassis must always match the Enclosure
Chassis ID displayed on the GUI.
Oracle FS1–2 Global Procedures
41
