Table 25: Low voltage dual phase PDU for Oracle Flash Storage Systems
Low Voltage 2Ph (2W + ground)
kVA size 10 kVA
Marketing part number 7104982
Phase 1 Phase
No grounded neutral conductors are
provided in the tw
o input cords.
Voltage input 2x [2Ph (2W+ground)], 208Vac, 50/60 Hz,
maximum. 24A
per phase
Can be connected to input sources in the
range of 200V – 240V AC (nominal)
Number of input cords and plug type 2x NEMA L6-30P
Number of data center receptacles and
type
2x NEMA L6-30R
Maximum input current for each cord 24A
Outlet receptacles (number/type) 42/C13 (seven for each outlet group)
6/C19 (one for each outlet group)
Outlet groups for each PDU 6
PDU power cord length 2 meters (6.6 feet)
PDU power cords are 4 m (13 ft) long, but
only 2 m (6.6 ft) are usable outside of the
cabinet.
Table 26: Low voltage three-phase PDU for Oracle Flash Storage Systems
Low Voltage 3Ph (3W + ground)
kVA size 15 kVA
Marketing part number 7104979
Phase 3
No grounded neutral conductors are
provided in the input cords.
Oracle FS System Hardware Specifications
236
