Oracle FS1-2 - Figure 4: Exploded View of Controller Replaceable Components

Legend
1 ESM modules (0,1,2,3)
2 Filler panels
3 Controller Unit Identication Display (CUID)
The following gure shows all the replaceable components of the Controller.
Figure 4: Exploded view of
Controller replaceable components
