Figure 35: Front of the rack and rail-location pegs
Legend
1 Rail-location pegs 2 Front rack post
4 Insert and tighten one Phillips 13mm head hex ange screw through the
front rack hole and into the top hole of the rail.
Oracle FS1–2 Global Procedures
69
