Legend
1 Power supplies 7 Ethernet port (ETH-0)
labeled as NET
-3
2 PCIe card slot 1 8 Ethernet port (ETH-1)
labeled as NET
-2
3 PCIe card slot 2 9 Ethernet port (ETH-2)
labeled as NET-1
4 PCIe card slot 3 and PCIe 4 slot (PCIe 4 slot is
for the internal SAS HBA
card and is not visible
from the back of the Pilot)
10 Ethernet port (ETH-3)
labeled as NET-0
5 ILOM SP network management port (labeled
as NET MGT port)
11 USB connectors
6 Serial management port (labeled as SRMGT
port)
12 Video connector
The following gure shows the components located at the front of the Pilot.
Figure 8: Pilot front view
Legend
1 Product serial number RFID tag 3 Front indicator module (FIM)
2 Power buon 4 Pilot boot drive
The following gure shows an exploded view of the Pilot
.
Introduction to Oracle FS1-2 System Service Procedures
29
