Legend
1 Pilot baery
2 Pilot motherboard
Note: Ensure that all pow
er is removed from the Pilot before removing or
installing the baery. You must disconnect the power cords from the Pilot before
performing these procedures.
Note: The baery can be accessed only after removing the cover over the Pilot
chassis.
Procedure Overview
1 Prepare a Pilot for Component Replacement
2 Slide Pilot to Service Position
3 Power O the Pilot
4 Open Pilot Fan Door
5 Open Pilot Top Cover
6 Remove a Baery
7 Insert a Baery
8 Close Pilot Top Cover
9 Close Pilot Fan Door
10 Slide Pilot to Rack Position
11 Connect Power Cords On the Pilot
12 Verify Component Replacement on the Standby Pilot
13 Verify Component Replacement on the Active Pilot
Related Links
Pilot Components
Prepare a Pilot for Component Replacement
1 Contact Oracle Customer Support prior to replacing a Pilot component.
Oracle Customer Support identies the failed component on the Pilot for
you.
2 From Oracle FS System Manager (GUI), navigate to System > Hardware >
Pilots and select the Pilot that contains the component that you want to
replace.
3 Select Actions > Repair Pilot.
Guided Maintenance displays the list of Pilot components.
4 Based on the information from your Oracle Customer Support
representative, select the correct component from the list.
Pilot Replacement Procedures
177
