Oracle FS1-2 User Manual

Figure 6: DE2-24C Drive Enclosure CRUs
Legend
1 Drives 4 I/O module 0
2 Power cooling module 1 5 I/O module 1
3 Power cooling module 2
The following table provides a summary of the Drive Enclosure components.
Table 3: Drive Enclosure component descriptions
Drive Enclosure component Component Type Hot serviceable
Chassis for the DE2-24P Drive
Enclosure
FRU No
Chassis for the DE2-24C Drive
Enclosure
FRU No
Introduction to Oracle FS1-2 System Service Procedures
26
