One slide rail that aaches to the rack posts
•
One mounting bracket that aaches to the Controller chassis
•
CMA
with six pre-installed cable clips
•
Package of mounting screws and nuts in assorted sizes to t various types
of racks and cabinets
•
Manufacturer's instruction sheet for the CMA
The following table summarizes the mounting hardware packaged with the
Controller rail kits.
Table 14: Controller rail kit mounting screws
Contents of the mounting screw packet Quantity Usage
10-32 pan head screw
8
Assemble main and
extender sections of
left and right rails
(T
ypically, left and
right rails are shipped
pre-assembled)
8-32 pan head screw
4
Mount left and right
rails to front of
cabinet rails
Metric M6 pan head screw
8
•
Mount left
and right rails
to back of
cabinet rails
•
Secure front
of chassis to
left and right
cabinet rails
6–32 at head screw
2
Secure back of chassis
to left and right side
rails
Tip: Ensure that y
ou have all of the parts in the Controller rail kit before you
begin the installation of the Controller rails on the rack and the Controller
chassis.
Note: To locate part numbers for the rail kits, open Oracle System Handbook
(hps://support.oracle.com/handbook_private/index.html) and go to the
Oracle FS1 Flash Storage System components list. Part numbers are listed in the
components list.
Related Links
Controller Rails
Oracle FS1–2 Global Procedures
45
