Legend
1 Top cover (with service label) 9 DIMMs 17 Riser
2 LED assembly 10 Fan compartment 18 Baery
3 Fan modules 11 PDB risers 19 NV-DIMM
4 CUID 12 ESM backplane boards 20 Heat sink
5 Energy storage modules (ESMs) 13 Power supply 21 CPU
6 Air lter 14 PDB duct 22 PDB cover
7 Motherboard cable kit 15 Air duct
8 Filler panels for DIMM slots 16 HBA
Related Links
Replace a Contr
oller Riser
Replace Controller Air Filter
Replace a Controller DIMM
Replace a Controller Energy Storage Module (ESM)
Replace a Controller Fan Module
Replace a Controller HBA
Replace a Controller Power Supply
Replace a Controller Riser
Drive Enclosure Components
When replacing a component, you must know its part number and whether it is
hot serviceable. Having that information helps you to order the correct
replacement component and to determine whether you can replace the
component yourself. To locate part numbers, open Oracle System Handbook
(hps://support.oracle.com/handbook_private/index.html). The part numbers are
listed in the Oracle FS1 Flash Storage System components list.
The Drive Enclosure chassis is a eld replaceable unit (FRU). The remaining
components of both Drive Enclosure types are customer replaceable units (CRU).
Drive Enclosure CRUs are hot serviceable.
Warning: Do not power‑cycle a Drive Enclosure. Power‑cycling a Drive Enclosure
impacts the primary and secondary data paths in the Drive Enclosure and puts
user data at risk.
The following gure shows the CRUs in the DE2-24P Drive Enclosure.
Introduction to Oracle FS1-2 System Service Procedures
24
